Floodlight

LED Floodlight

Application Areas:

Billboard, Wall Washing, Gardening,
Parking Lot, Outdoor

  • 25W / 40W
  • 1,950lm – 3,950lm
  • IP65 water proof, dust proof
  • Excellent Light Uniformity
  • Ultra Low Junction Temperature
  • Maximized Lifespan

Uniformity Design


DL Series Dimension

DL_feature_size


Operating Environment

101

104

107

103

112

Model Number DL25-30 DL25-40 DL25-50 DL40-30 DL40-40 DL40-50
Power (W) 25 40
Lumen Output (lm) 1,950 2,250 2,400 3,200 3,550 3,950
Color Temperature (K) 3,000 4,000 5,000 3,000 4,000 5,000
Lumen per Watts of Light (lm/w) 78 90 96 80 89 99
CRI 65 – 80
Input Voltage Range (VAC) 100 – 277
Beam Angle 110°
Operating Temp (°C) -20 ~ 40
Operating Environment Billboard, Parking Lot, Gardening, Wall Washing, Outdoor
Dimension (mm) 222(L)*84(W)*195(H) mm 239(L)*84(W)*195(H) mm
Fixture Weight (kg) 1.5 1.9
IP rating IP65

*Note: Specifications is subject to change without notice.

Order Guide

Sample Number : DL25-50NSS-SBT

Model Watts Color Temp Dimmable Beam Angle Color Mounting
DL 25 30=3000K N=Non Dimmable* S=Standard S=Silver SBT=Yoke Mount*
40 40=4000K D=0v-10v Dimmable
N=Non Dimmable
B=Black
50=5000K W=White

*Note: Dimmable type only for DL 40 Series.

Simulation / DL 25W / 5,000K


Lux at a distance / DL 25W / 5,000K


Spatial distribution / DL 25W / 5,000K


Polor Luminous Intensity Distribution


Intensity distribution

Yoke Mount (SBT)
